RM 885.00
SKU: DC-X2
The lightweight DC-X2 6" Touchscreen HD Monitor from Viltrox lets you view your camera's image on a bright, sharp 6" display. The DC-X2 supports up to DCI/UHD 4K30 via the HDMI video input and can send the signal through an HDMI loop-through output to another display. This model features multiple image tools such as histogram and waveform, and its 2000 cd/m² brightness makes it suitable for indoor or outdoor use.
The DC-X2 features a 1920 x 1080 display that supports live view from your camera, and you can monitor the audio via its 3.5mm headphone port. The SD card slot or the USB port can be used to upgrade the firmware or to add custom 3D LUT files to apply to your view. At the rear of the monitor, a built-in L-series battery plate enables you to power the monitor with the L-series battery, or you can power it with a separately available DC barrel or USB-C adapter. The camera mounts onto a cage, camera, or rig using the included shoe adapter mount, and a sun hood is available to protect the monitor from glare.
Features
Daylight-viewable, 6" on-camera LCD monitor with 1920 x 1080 resolution
The DC-X2 features 2000 cd/m² brightness for indoor and outdoor use
Full-size HDMI input, full-size HDMI loop-through output
Supports up to DCI/UHD 4K30 video input and output
Power the monitor with a separately available DC barrel or USB-C power adapter or via Sony L-series type batteries in the built-in battery plate
Import custom 3D LUTs via a separately available SD card using the built-in slot or via USB, which can also be used for firmware updates
Key Specs
| Display Size |
6.0" / 15.2 cm |
| Native Resolution |
1920 x 1080 |
| Touchscreen |
Yes |
| HDR Support |
No |
| Video I/O |
1 x HDMI 1.4 Input |
| Media/Memory Card Slot |
Single Slot: SD (Unspecified Type) [LUT/Firmware Update Only] |
| Video Format |
HDMI |
| Battery |
1x L-Series Mount on Fixed Plate |
| Power Consumption |
13.5 W |
Display
| Panel Type |
LCD |
| Display Size |
6.0" / 15.2 cm |
| Native Resolution |
1920 x 1080 |
| Aspect Ratio |
16:9 |
| Touchscreen |
Yes |
| Maximum Brightness |
2000 nits / cd/m2 (Peak) |
| Contrast Ratio |
1000:1 |
| Color Support |
16.7 Million Colors (8-Bit) |
| HDR Support |
No |
| Color Gamut |
100% Rec. 709 |
| LUT Support |
No |
| Image Controls |
False Color, Histogram, Image Flip, Pixel-to-Pixel Zoom, RGB Parade, Waveform |
Inputs/Outputs
| Video I/O |
1 x HDMI 1.4 Input |
| Embedded Audio |
HDMI |
| Audio I/O |
1x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker |
No |
| Power I/O |
1x Barrel (12 VDC / 2 A) Input |
| Other I/O |
No |
| Media/Memory Card Slot |
Single Slot: SD (Unspecified Type) [LUT/Firmware Update Only] |
Wireless
| Wi-Fi |
No |
| Bluetooth |
No |
| Mobile App Compatible |
No |
Format Support
| Video Format |
HDMI |
Power
| Input Power |
12 to 18 VDC at 2 A |
| Battery |
1x L-Series Mount on Fixed Plate |
| Power Consumption |
13.5 W |
Mounting
| Tripod/Accessory Mounting |
Bottom/Right |
General
| Operating Conditions |
32 to 149°F / 0 to 65°C |
| Storage Conditions |
32 to 167°F / 0 to 75°C |
| Material of Construction |
Aluminum |
| Dimensions |
6.12 x 3.87 x 1.06" / 15.54 x 9.84 x 2.68 cm |
| Weight |
11.4 oz / 324.5 g |
Packaging Info
| Package Weight |
2.875 lb |
| Box Dimensions (LxWxH) |
12 x 6.6 x 2.9" |
