Hollyland Mars M1 Enhanced 5.5" Wireless Transceiver Monitor

RM 2099.00

  • Wirelessly Monitor Video from up to 450'
  • Transmitter & Receiver Mode Switching
  • New Capsule Antennas & Record/Playback
  • 5.5" Touchscreen 1920 x 1080 Display
  • Up to 4K30 Video SDI Input, HDMI In/Out
  • Presets & USB-C 3D LUT Import
  • High 1000 cd/m² Brightness
  • Low 0.08s Latency, Smart Channel Scan
  • DC Power Input & Output
  • Built-In L-Series Battery Plate

SKU: HL-MARS M1 ENHANCED

Out of Stock
  Price Match

  Wishlist

Transmit, receive, and monitor high-quality wireless video transmissions using this compact Mars M1 Enhanced 5.5" Wireless Transceiver Monitor from Hollyland. The Mars M1 Enhanced provides new features including a record/playback review feature that can review up to 2 minutes of video for instant review, and it features a new low-profile capsule antenna design. As with the original M1, it features a 5.5" touchscreen display that provides a sharp resolution and 1000 cd/m² brightness for follow focus and director's monitoring applications. Its built-in wireless transmitter and receiver allow you to send and receive video between M1 units as well as to/from the Mars 400S Pro, Mars 300 Pro, and Mars 4K wireless transmitters/receivers at a distance of up to 450'. You can also monitor video from the M1 Enhanced on smartphones and tablets running the companion HollyView app.

The monitor supports up to DCI/UHD 4K30 video input via its HDMI input, and it features an HDMI loop output and an SDI input that supports multiple broadcast drop-frame frame rates. Multiple imaging tools are available using the built-in HollyOS firmware, including scopes, peaking, and storage of 3D LUTs on the monitor. It can be powered using its built-in L-series battery plate or via its DC input. It also features a DC power output, so you can power your camera or other gear.

Display with Professional Color Calibration

The Mars M1 Enhanced is designed with a 5.5" 1920 x 1080 resolution touch LCD screen with 1000 cd/m² brightness. Professional color calibration is performed during manufacturing, and multiple-level color temperature adjustments are available. The screen supports the Rec. 709 color gamut for excellent color rendition, 16:9 aspect ratio, and 16.7M natural colors.

Compatibility

The Mars M1 Enhanced is an all-in-one transmitter, receiver, and monitor solution that M1 can be used either as a transmitter or a receiver. As well as transmitting between two M1 units, the M1 can also transmit and receive from all Mars 300 Pro, Mars 400S Pro, and all Mars 4K models, as well as to smartphones and tablets with the HollyView app.

Input/Output

The Mars M1 Enhanced features HDMI input and HDMI loop output, one 3G-SDI input, as well as a 3.5mm headphone output.

Wirelessly Transmit and Receive Video

The Mars M1 Enhanced supports up to DCI/UHD 4K30 HDMI input and output for expanded connectivity and compatibility. The SDI provides expanded frame rate flexibility for both broadcast and production frame rate standards and compatibility through production and postproduction.

Trigger Recording and Video Playback

The Mars M1 Enhanced is engineered for automatic trigger recording and video playback. Replay your video wherever and whenever you want to ensure it is captured at its finest quality. The video recording function supports up to two minutes of recording time.



NOTE: The recorded video cannot be exported and will be deleted when the device is turned off or when a new recording is started.

3D LUT File Import

Selectable 3D LUT presets are available to map the colors to the monitor for a consistent, high-quality effect. You can also load your own custom LUTs.

Smart Channel Scan

Smart Channel Scan enables you to find the interference-free option for a stable connection experience. The optimum channel is selected automatically upon startup.

Wireless Range

Transmission distance up to 450'.

HollyOS

Powered by Hollyland's HollyOS operating system, the Mars M1 Enhanced offers a comprehensive suite of advanced monitoring tools, such as waveform, vectorscope, zebra pattern, aspect mark, anamorphic de-squeeze, crosshatch, and more. Each of these tools provides you with complete control over your image, offering an opportunity to fine-tune every shot to your specific preferences.

Power Options

The Mars M1 Enhanced supports three types of power supply: 7 to 16 VDC power input, L-series (NP-F970/750/550) battery (purchased separately), and via a D-Tap connector with a separately available power source.

App Monitoring

The Hollyview app for Android and iOS allows you to monitor your transmission on a smartphone or tablet. It allows you to transmit to apps and receivers and receive from transmitters such as the Mars 400S Pro or Mars 4K in the following configurations:

  • One Mars M1 Enhanced TX can send signals to two other Mars M1 Enhanced set in RX mode
  • One Mars M1 Enhanced TX can send signals to one other Mars M1 Enhanced set in RX mode and up to two devices running the HollyView app
  • One Mars M1 Enhanced TX can send signals to four devices running the HollyView app
  • One Mars M1 Enhanced TX can send signals to two other Hollyland Mars 400S Pro/Mars 300 Pro/Mars 4K RX units
  • One Hollyland Mars 400S Pro/Mars 300 Pro/Mars 4K TX unit can send signals to one Mars M1 Enhanced set in RX mode and up to two devices running the HollyView app

Fan Mode

The Mars M1 features a built-in fan with the choice to select Auto or Mute in the menu. Mute mode keeps the monitor working with lower fan noise without affecting video recording.

Hollyland Mars M1 Enhanced Specs

Key Specs

Display Size

5.5" / 14.0 cm

Resolution

1920 x 1080

Touchscreen

Yes

Video I/O

1 x HDMI (Unspecified Signal) Input
1 x BNC (3G-SDI) Input
1 x HDMI (Unspecified Signal) Loop Output

Embedded Audio

HDMI/SDI

Latency

No

Video Format

HDMI
DCI 4K: 30/29.97/25/24/23.98
UHD 4K: 30/29.97/25/24/23.98
1080p: 60/59.94/50/30/29.97/25/24
1080i: 60/59.94/50
720p: 60/59.94/50
SDI
1080p: 60/59.94/30/29.97/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50

Battery Type

1 x L-Series

Power Consumption

16 W (Maximum)

Mounting

2 x 1/4"-20 Female

Display

Panel Type

LCD

Display Size

5.5" / 14.0 cm

Resolution

1920 x 1080

Aspect Ratio

16:9

Touchscreen

Yes

Image Controls

Focus Peaking, Waveform

Inputs / Outputs

Antenna I/O

2 x RP-SMA Male

Video I/O

1 x HDMI (Unspecified Signal) Input
1 x BNC (3G-SDI) Input
1 x HDMI (Unspecified Signal) Loop Output

Embedded Audio

HDMI/SDI

Audio I/O

1 x 1/8" / 3.5 mm Headphone Output

Power I/O

1 x Barrel (16 VDC) Input
1 x Barrel Output

Other I/O

1 x USB-C (Firmware) Input

Encryption

No

Wireless

Wireless Range

450' / 137.2 m (Line-of-Sight)

Channel Bandwidth

20 MHz

Frequency Range

US: 5.15 to 5.25 GHz
US: 5.25 to 5.35 GHz
US: 5.47 to 5.725 GHz
US: 5.725 to 5.85 GHz

Latency

No

RF Power

21 dBm

Wi-Fi

No

Bluetooth

No

Mobile App Compatible

Yes, Required: Android & iOS
App Name: HollyView
Functionality: Adjust Settings, Firmware Update, Remote Control, Setup, View Live Feed
*As of October, 2023: Check with manufacturer for the most up-to-date compatibility

Cellular Support

No

Format Support

Video Format

HDMI
DCI 4K: 30/29.97/25/24/23.98
UHD 4K: 30/29.97/25/24/23.98
1080p: 60/59.94/50/30/29.97/25/24
1080i: 60/59.94/50
720p: 60/59.94/50
SDI
1080p: 60/59.94/30/29.97/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50

Wireless Video Compression

Compressed

Timecode Support

Yes

Power

DC Input Power

7 to 16 VDC

Battery Type

1 x L-Series

Power Consumption

16 W (Maximum)

Mounting

Mounting

2 x 1/4"-20 Female

Environmental

Environmental Protection

No

Certifications

FCC

Operating Temperature

14 to 140°F / -10 to 60°C

Storage Temperature

-40 to 140°F / -40 to 60°C

General

Material of Construction

Plastic

Dimensions

6 x 3.8 x 1.6" / 152 x 96 x 40 mm, Excluding Antenna

Weight

14.1 oz / 400 g, Excluding Antenna

  • Wirelessly Monitor Video from up to 450'
  • Transmitter & Receiver Mode Switching
  • New Capsule Antennas & Record/Playback
  • 5.5" Touchscreen 1920 x 1080 Display
  • Up to 4K30 Video SDI Input, HDMI In/Out
  • Presets & USB-C 3D LUT Import
  • High 1000 cd/m² Brightness
  • Low 0.08s Latency, Smart Channel Scan
  • DC Power Input & Output
  • Built-In L-Series Battery Plate
  • Hollyland Mars M1 Enhanced 5.5" Wireless Transceiver Monitor
  • 2 x Capsule Antenna
  • Tempered Glass Screen Protector
  • USB-C Converter
  • D-Tap to Locking DC Power Cable
