Panasonic UE50 4K30 SDI/HDMI PTZ Camera with 24x Optical Zoom (White)

RM 21280.00

  • 1/2.5" 4K MOS Sensor
  • Up to UHD 4K30 & HD Simultaneous Out
  • HDMI 1.4, SDI, USB & IP Video Output
  • 24x Optical, 28x UHD & 36x HD iZoom
  • Wide 74.1° Horizontal Angle of View
  • PoE+ Support, IP, USB & RS-422 Control
  • Stream 1080p to Platforms via H.264/265
  • Stereo Mini-Jack Audio Mic/Line Input

SKU: AW-UE50WPJ

Out of Stock
  Price Match

  Wishlist

Panasonic AW-UE50 Overview




Bring UHD 4K quality video to your production with the white UE50 4K30 SDI/HDMI PTZ Camera from Panasonic. This pro PTZ camera outputs up to UHD 4K30 over HDMI 1.4, up to 1080p60 over SDI, and it supports IP live streaming up to 1080p to fit into any environment such as a conference room or classroom. The camera can also be used as a webcam with the built-in USB Type-C port. It features a large 1/2.5" MOS sensor, a 24x optical zoom with a wide 74.1° angle-of-view, and PoE+ compatibility for single-cable operation.

The UE50 supports embedded audio and audio input via a stereo mini-jack for embedding into your output stream. Its redesigned web interface is compatible with Windows and macOS computers as well as Android and iOS smartphones. Additional features include a red/green tally light, extended 28x UHD 4K digital zoom, extended 36x Full HD digital zoom, and live streaming via H.264/H.265 codecs. The camera can be remotely controlled via IP, RS-422, or via its USB Type-C port via UVC 1.0/UAC 1.0. The camera is upgradable to NDI/HX compatibility or subject tracking with separately available licenses.

Stable Environment for Online and Offline
4K resolution with wide-angle and high-magnification zoom for capturing all aspects of your room.
Secure and stable streaming protocol for reduced risk of communication trouble.
Smooth playback of high-quality videos.
Optional auto-racking software is available for reliable following and capturing of the speaker.
Compact Size and Quiet Operation
The compact dome-shape design blends in with the surroundings. Its light weight and small size give added flexibility in camera installation.
Quiet operating sound allows the use of the camera in any situations.
Integrated optical image stabilization ensures stable video shooting.
Flexibility for Smooth Operation
Easy installation and operation even for inexperienced staff or small staff.
Single computer via USB or optional IP or serial controller can manage and control multiple cameras.
The camera can be used as a USB webcam.
The camera can stream video directly to a live streaming service.

Panasonic AW-UE50 Specs

Key Specs
Image Sensor
1/2.5"-Type MOS
Shutter Speed
1/10000 to 1/25 Second
Optical Zoom Ratio
24x
Max Digital Zoom
36x ( in 1080p)
Video Output
RJ45 / USB
1920 x 1080p at 25/29.97/50/59.94 fps
1280 x 720 at 25/29.97/50/59.94 fps
640 x 360 at 25/29.97/59.94 fps
320 x 180p at 25/29.97/50/59.94 fps
SDI/BNC
1920 x 1080p at 23.98/24.00/25/29.97/50/59.94 fps
1920 x 1080i at 50/59.94 fps
1920 x 1080PsF at 23.98/25/29.97 fps
1280 x 720 at 50/59.94 fps
4:2:2 10-Bit via HDMI
3840 x 2160 at 24.00/25/29.97 fps
1920 x 1080p at 23.98/24.00/25/29.97/50/59.94 fps
1920 x 1080i at 50/59.94 fps
1280 x 720 at 50/59.94 fps
Broadcast Output
NTSC/PAL
IP Streaming
H.264/MJPEG/H.265 via UDP/TCP/SRT/RTSP/RTP/RTMPS/RTMP/NDI|HX
320 x 180 to 1920 x 1080
Supported Control Protocols
RS-422
PoE Support
PoE+ 802.3at
Key Features
  • 1/2.5" 4K MOS Sensor
  • Up to UHD 4K30 & HD Simultaneous Out
  • HDMI 1.4, SDI, USB & IP Video Output
  • 24x Optical, 28x UHD & 36x HD iZoom
  • Wide 74.1° Horizontal Angle of View
  • PoE+ Support, IP, USB & RS-422 Control
  • Stream 1080p to Platforms via H.264/265
  • Stereo Mini-Jack Audio Mic/Line Input
  • Panasonic UE50 4K30 SDI/HDMI PTZ Camera with 24x Optical Zoom (White)
  • Power Supply

PTZ  Camera
