DJI Mic 3 Camera-Mount Wireless Receiver

RM 519.00

  • For DJI Mic 3 Wireless Mic Systems
  • Camera-Mount 4-Channel Receiver Unit
  • Dual-Band Wireless, Bluetooth 5.4
  • Timecode I/O Support
  • AMOLED Touchscreen, Onboard Controls
  • 3.5mm Line Out, 3.5mm Headphones Out
  • USB-C Audio Adapter
  • 10-Hour Battery Runtime

SKU: CP.RN.00000477.01

Package

Out of Stock
  Price Match

  Wishlist

DJI Mic 3 Rx Overview

Part of DJI's Mic 3 wireless system, the Camera-Mount Wireless Receiver is a compact, 2-channel receiver available individually to expand your existing setup or serve as a backup. It supports stereo and mono audio channels and can be paired with up to four Mic 3 transmitters and seven additional receivers for multi-person audio capture across a variety of production environments. The receiver features support for both timecode input and output for improved postproduction workflows.

A 3.5mm TRS output allows direct audio recording to your camera, while a dedicated 3.5mm headphone jack provides real-time monitoring. An included USB-C adapter allows you to plug it directly into your mobile device. Purchase the separately available Mic Series Camera Adapter for direct compatibility with Sony MI shoes. Dual-band wireless and Bluetooth 5.4 technology ensure communication from up to 1312' away. An AMOLED touchscreen and onboard controls let you adjust parameters directly from the receiver. Further control is available via the DJI Mimo mobile app. The built-in rechargeable battery delivers up to 10-hour runtime.

Additional Details

  • 4-channel receiver pairs with up to four DJI Mic 3 transmitters and seven additional receivers
  • Dual-band wireless support, Bluetooth 5.4
  • Mounts on camera with built-in shoe adapter
  • 3.5mm TRS audio output to camera, 3.5mm headphone jack
  • USB-C charging port, USB-C audio adapter
  • Separately available Camera Adapter connects receiver directly to MI shoes
  • Timecode I/O support
  • AMOLED touchscreen, onboard controls
  • Rechargeable battery with 10-hour runtime

DJI Mic 3 Rx Specs

Key Specs

Wireless Technology

Digital 2.4 GHz / Digital 5.8 GHz / Bluetooth

Diversity

Non-Diversity

Max Operating Range

1312.3' / 400 m (Line of Sight)
262.5' / 80 m (with Obstruction)

Receiver Type

1x Camera-Mount

Number of Audio Channels

2

System

Wireless Technology

Digital 2.4 GHz / Digital 5.8 GHz / Bluetooth

Diversity

Non-Diversity

RF Frequency Band

2400 to 24,835 MHz / 5150 to 5250 MHz / 5250 to 5350 MHz / 5470 to 5725 MHz / 5725 to 5850 MHz

Max Operating Range

1312.3' / 400 m (Line of Sight)
262.5' / 80 m (with Obstruction)

Max Transmitters per Band

4

Built-In Recorder

No

Timecode Support

Yes

Mobile App Compatible

Yes: Android & iOS
App Name: DJI Mimo

Receiver

Receiver Type

1x Camera-Mount

Mounting Options

Shoe-Mount (with Included Hardware)
USB-C Plug-In (with Included Adapter)

Antenna

1x Internal

Number of Audio Channels

2

Audio I/O

1x 1/8" / 3.5 mm TRS Unbalanced Output

Network I/O

No

USB/Lightning Connectivity

1x USB-C Female

Display

OLED

Power Requirements

Battery

Power

Receiver Battery Type

1x Built-In Rechargeable - 275 mAh

Receiver Battery Life

10 Hours

Battery Charging Time

50 Minutes

AC/DC Power Adapter

No

Input Power

5 VDC

Physical

Environmental Resistance

No

Dimensions

2.1 x 1.1 x 0.9" / 53.9 x 28.7 x 22 mm

Weight

0.9 oz / 25.1 g

  • For DJI Mic 3 Wireless Mic Systems
  • Camera-Mount 4-Channel Receiver Unit
  • Dual-Band Wireless, Bluetooth 5.4
  • Timecode I/O Support
  • AMOLED Touchscreen, Onboard Controls
  • 3.5mm Line Out, 3.5mm Headphones Out
  • USB-C Audio Adapter
  • 10-Hour Battery Runtime



  • DJI Mic 3 Camera-Mount Wireless Receiver
  • DJI Mic 3 Mobile Phone Adapter (USB-C)
  • USB-C to USB-C Data Cable
  • DJI Mic 3 Locking 3.5mm TRS to TRS Audio Adapter Cable
  • Carrying Pouch
