Blackmagic Design OpenGear Converter SDI to Analog Module

RM 2630.00

Warranty: 1 Year by Malaysia Distributor

SKU: BMD-CONVOPENGASA

  Add to Cart
  Price Match

  Wishlist



The OpenGear Converter SDI to Analog Module from Blackmagic Design is a component designed for use in the modular OpenGear system. OpenGear is essentially an open-standards chassis that can be mounted in a rack for conversion and processing work. The chassis accepts different modules to enhance its functionality, allowing the solution to be expanded or scaled at will.



This module is designed to convert SDI to analog HD/SD component, NTSC and PAL video, and balanced AES/EBU and analog audio output. It is well suited for use with Betacam SP, VHS, set-top boxes, gaming consoles, and HDV cameras, among other possible equipment and applications. It also features a built-in, hardware down-converter to connect HD-SDI video to SD equipment.

SDI to Analog Conversion
Use this module to convert SDI to analog HD/SD component, NTSC and PAL video, and balanced AES/EBU and analog audio output.
OpenGear System
This module is intended for use in the OpenGear modular chassis.

Blackmagic Design OpenGear Specs

Input SDI: 1 x channel switchable between SD, HD and 3Gbs SDI
Output Analog Video:
1 x component, NTSC, PAL and S-video from SD-SDI input
1 x component HD from HD-SDI input
Analog Audio
2 x channels of professional balanced analog audio with standard 1/4" jack
AES/EBU Digital Audio
2 x channels of professional balanced digital with standard 1/4" jack
Standards SDI Format Support:
625/25 PAL, 525/29.97 NTSC, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080i50, 1080i59.94, 1080i60, 720p50, 720p59.94 and 720p60.
SDI Compliance:
SMPTE 292M, SMPTE 259M, SMPTE 296M, ITU-R BT.656, ITU-R BT.601 and SMPTE 297M for Optical Fiber SDI
SDI Video Sampling:
4:2:2
SDI Video Rates:
SDI video connections are switchable between standard definition and high definition.
SDI Color Precision:
4:2:2
SDI Color Space:
YUV
SDI Audio Sampling:
Television standard sample rate of 48 kHz and 24 bit
SDI Auto Switching:
Automatically selects between SD SDI, HD-SDI and 3 Gbs SDI
Analog Format Support:
625/25 PAL, 525/29.97 NTSC, 1080PsF23.98, 1080PsF24, 1080i50, 1080i59.94, 1080i60, 720p50, 720p59.94 and 720p60
Analog Color Precision:
4:2:2
Analog Color Space:
YUV
HDMI Format Support:
625/25 PAL, 525/29.97 NTSC, 625/50p PAL, 525/59.94p NTSC, 1080p23.98/24, 1080i50, 1080i59.94/60, 720p50 and 720p59.94/60
HDMI Color Precision:
4:2:2 and 4:4:4
HDMI Color Space:
YUV and RGB
Copy Protection:
For legal reasons, capture devices from Blackmagic Design are designed not to capture, convert or transmit video or audio from copy-protected sources, e.g. video devices using HDCP
Dimensions (HxWxD) Not specified by manufacturer
Weight Not specified by manufacturer
