Metabones Canon EF to BMPCC4K Ultra 0.71x Cine Speed Booster Adapter

RM 3631.00

Warratny: 1 Year by Local Distributor

SKU: MB-SPEF-M43-BTA

  Add to Cart
  Price Match

  Wishlist

The T CINE Speed Booster ULTRA 0.71x Adapter for Canon EF Lens to BMPCC 4K from Metabones allows a full-frame Canon EF-mount lens to be mounted onto a Blackmagic Design Pocket Cinema Camera 4K MFT-mount camera. While doing so, the adapter's optics help to maximize the connected lens's apparent angle of view while providing a 1-stop increase for the camera over the lens's aperture range. This 0.71x adapter features Cinema EOS lens support for auto iris and servo zoom, and it also includes AF (autofocus) support which requires external 5V power via the micro-USB port. It also features a positive-lock mechanism for EF lenses.

If a lens intended for 35mm film or similarly sized full-frame camera sensors is connected to a camera with a Micro Four Thirds-sized sensor, it would project an image larger than the Micro Four Thirds sensor was built to accept. Able to capture only the center portion of the projected image, the effective angle of view of the lens would be narrowed, creating an in-camera "crop factor." The T CINE Speed Booster ULTRA 0.71x adapter condenses the light from a lens designed for 35mm film or "full-frame" camera sensors and projects it onto a Micro Four Thirds sensor. This allows the Blackmagic Pocket Cinema Camera 4K with a Micro Four Thirds sensor to utilize more of the light gathered by a connected lens, which effectively reduces the crop factor while making available to the sensor an additional 1-stop of light for each of the lens's f/stop settings.

This adapter is constructed from aluminum for durability while minimizing weight and its mounting rings are made with brass to further prevent wear and tear. The internal lens elements are designed to provide optical clarity as well as color fidelity, and a detachable tripod foot is included and features 1/4"-20 threads as well as compatibility with Arca-Swiss tripod heads.

The T CINE Speed Booster ULTRA 0.71x adapter supports electronic communication between an attached camera and lens. If the lens includes autofocus, image stabilization, and camera-controlled aperture functions, this adapter is intended to allow those features to be used. Also, if an attached lens is capable of generating EXIF metadata when used with a directly compatible camera, the T CINE Speed Booster ULTRA 0.71x adapter is designed to allow that information to be saved along with image files generated with a combination of the lens, a BMPCC 4K camera, and the adapter.

Adapter

Camera Mount Micro Four Thirds
Lens Mount Canon EF
Magnification 0.71x
Optical Design 6 Elements in 4 Groups

Physical

Material Aluminum, Brass
Tripod Mounting Thread 1/4"-20 Female
Dimensions H: 3.5D: 1.6" / H: 90.0D: 40.0 mm
Weight 12.70 oz / 360 g

Key Features

  • Allows a full-frame Canon EF-mount lens to be used with a Blackmagic Design Pocket Cinema Camera 4K MFT-mount camera
  • Maximizes apparent angle of view of combined camera and lens
  • Cinema EOS lens support, including AF (requires external 5V power via micro-USB port), auto iris, and servo zoom
  • Provides a 1-stop increase for the camera over the lens's aperture range
  • Integrated jog dial for incremental aperture adjustment and push-button access to lens's widest aperture setting when used with a compatible Panasonic camera
  • 6 lens elements in 4 groups for optical clarity as well as color fidelity
  • Supports electronic communication between camera and lens to enable autofocus, image stabilization, on-camera aperture control, and EXIF metadata generation when possible
  • Internal coating minimizes reflections within the adapter barrel
  • Detachable, Arca-Swiss compatible tripod foot with 1/4"-20 threads matches the BMPCC 4K camera height
  • Aluminum components for weight reduction
  • Brass mounting rings prevent wear and tear
  • Special positive-lock EF mount for secure attachment of lens with push-button release

Camera Compatibility

Blackmagic Pocket Cinema Camera 4K
Blackmagic Pocket Cinema Camera HD (original version)
Blackmagic Micro Cinema Camera
Blackmagic Micro Studio Camera 4K
Blackmagic Studio Camera 4K
Blackmagic Studio Camera

Lens Compatibility

Canon EF 100-400mm f/4.5-5.6L IS II USM
Canon EF 100-400mm f/4.5-5.6L IS USM (I)
Canon EF 100mm f/2.8L IS USM Macro
Canon EF 135mm f/2L USM
Canon EF 16-35mm f/2.8L II USM
Canon EF 17-35mm f/2.8L USM
Canon EF 17-40mm f/4L USM
Canon EF 200mm f/2.8L II USM
Canon EF 24-105mm f/4L IS USM (I)
Canon EF 24-70mm f/2.8L II USM
Canon EF 28-135mm f/3.5-5.6 IS USM
Canon EF 28-70mm f/3.5-4.5 II
Canon EF 28-80mm f/3.5-5.6 III USM
Canon EF 300mm f/2.8L IS II USM
Canon EF 300mm f/4L IS USM
Canon EF 400mm f/5.6L USM
Canon EF 40mm f/2.8 STM
Canon EF 50mm f/1.2L USM
Canon EF 50mm f/1.4 USM
Canon EF 50mm f/1.8 II
Canon EF 50mm f/1.8 STM
Canon EF 70-200mm f/2.8L IS II USM
Canon EF 70-200mm f/4L IS II USM
Canon EF 70-200mm f/4L USM
Canon EF 70-300mm f/4-5.6L IS USM
Canon EF 8-15mm f/4L USM Fisheye
Canon EF 85mm f/1.2L II USM
Sigma 135mm f/1.8 DG HSM Art 017
Sigma 24-105mm f/4 DG HSM Art 013
Sigma 24-35mm f/2 DG HSM Art 015
Sigma 30mm f/1.4 DC HSM Art 013
Sigma 35mm f/1.4 DG HSM Art 012
Sigma 50-500mm f/4.5-6.3 DG OS HSM
Sigma 50mm f/1.4 DG HSM (not Art)
Tamron 10-24mm f/3.5-4.5 VC HLD B023
Tamron 18-250mm f/3.5-6.3 A18
Tamron 18-270mm f/3.5-6.3 B003
Tamron 24-70mm f/2.8 VC USD A007 (G1)
Tamron 28-300mm f/3.5-6.3 A06
Tamron 35-150mm f/2.8-4 VC OSD A043
Tamron 70-200mm F/2.8 Di VC USD A009
Tokina 11-16mm f/2.8 AT-X PRO (I)
Zeiss 18mm f/3.5 ZE
Canon EF-Extender (Teleconverter)
